FlyfishRC Volador II VX5 O4 Pro FPV Freestyle T700 Frame Kit Black

Description

Description:-

 The FlyFishRC Volador II Frame, now available at Multirotors, is the next evolution of FlyFishRC’s popular 5-inch FPV platform. Developed with valuable feedback from pilots and testers worldwide, the Volador II incorporates numerous refinements to deliver an improved building experience, enhanced durability, and outstanding flight performance.

Designed with simplicity and versatility in mind, the Volador II offers broad compatibility with a wide range of analog and HD FPV systems currently available on the market. Whether you’re building a freestyle drone, a cinematic setup, or a high-performance FPV machine, the frame provides a clean and efficient platform for your electronics.

The Volador II VX features a Squashed X configuration for precise and responsive control, while the Volador II VD utilizes the popular Deadcat layout, keeping propellers out of the camera’s field of view for cleaner footage. Its independently replaceable arm design and tightly integrated structure help reduce frame resonance and unwanted vibrations, resulting in a smoother flight experience.

FlyFishRC has also introduced a specially designed silicone shock-absorbing camera mount insert optimized for the DJI O4 Air Unit camera. This innovative solution helps minimize jello effects in recorded footage while maintaining compatibility with standard 19mm and 20mm FPV cameras.

Constructed from premium T700 carbon fiber and high-strength CNC-machined aluminum alloy components, the Volador II offers an excellent balance of strength, durability, and weight savings. Smooth chamfered carbon edges not only improve the overall appearance of the frame but also help protect wires, battery straps, and other components from damage during installation and operation.

The upgraded battery pad features an enhanced anti-slip grid pattern and stronger adhesive backing to keep batteries securely in place during aggressive maneuvers. An integrated rear-mounted XT60 solution improves cable management and helps protect power leads from accidental propeller strikes during crashes.

Every Volador II frame includes the necessary accessories for both analog and digital builds, along with pre-treated hardware featuring thread-locking compound for added reliability and peace of mind. Carefully engineered TPU components further enhance protection, cable management, and overall aesthetics, allowing builders to achieve an exceptionally clean and professional-looking setup.

Available through Multirotors, the FlyFishRC Volador II Frame is an excellent choice for pilots seeking a premium FPV frame that combines durability, thoughtful engineering, clean assembly, and exceptional performance.

V2 Features:

High-end T700 carbon fiber

Tight structure design minimizes resonance

The new CNC aluminum camera plates effectively protect the camera The silicone shock-absorbers for the O4 AU eliminate jello Integrated XT60 connector for safety and reliability

High-quality TPU parts

Innovative anti-slip battery pads New motor wire protection tubes

Compatible with both 19/20mm cameras

Equipped with all accessories needed for analog and HD builds 12.9-grade strength hardware with Loctite threadlocker pre-applied High electronics compatibility

V1 to V2 notable differences:

The frame is now significantly lighter.

The new CNC side plate is lighter and perfectly fits the DJI O3 AU camera. The new battery anti-slip pad is more “sticky” and has better adhesion.

Added keystone to even further reduce arm vibration. Added bottom screw gasket.

Added motor wire protection tubes.

The four middle screws on the top plate are now countersunk and sit flush, to eliminate possible battery damage during crashes.

The new TPU arm protectors are now lighter and allow for easier disassembly.

All models now come with two types of TPU antenna mount (with or without GPS mount). The thickness of the bottom and middle plates has been adjusted to 2.5mm.

The connection structure between the arm and the clamp plate is slightly adjusted to distribute stress better.

XT60 plug cutout on the top plate is now symmetrical, allowing installation of the XT60 in both orientations.

VX5 Specifications:

Arm Thickness: 6mm

Top plate thickness: 2.5mm Middle plate thickness: 2.5mm Bottom plate thickness: 2.5mm Keystone thickness:5mm

Side plate thickness:2mm

CNC Side plate thickness:5mm Propeller size: 5~5.1 inch Material: T700 carbon plate FPV cam spacing: 19mm/20mm Weight: 177.4g(with TPU parts) Colour: Black/Yellow

Total Dimensions:177mm*165mm Wheelbase:225mm Stack mounting holes: 20mm*20mm/30.5mm*30.5mm(M3) VTX mounting holes: 20mm*20mm/25.5mm*25.5mm(M2) Motor mounting holes:16*16mm(φ3mm)

Includes:

1x Volador II VX5 Frame Kit
